ABB FAU800 MeasureIT Flame Analysis Unit

ABB FAU800 MeasureIT Flame Analysis Unit

  • Manufacturer: ABB

  • Product No.: FAU800

  • Product Type: MeasureIT Flame Analysis Unit

  • Product Origin: USA

  • Payment: T/T

  • Weight: 1000g

  • Shipping port: Xiamen

  • Warranty: 12 months

General Information

The MeasureIT Flame Analysis Unit, or FAU800, is ABB’s latest leading-edge flame analysis device.

The FAU800 is designed from the ground up for maximum flexibility, usability, and reliability. It takes advantage of the latest technologies available to make flame analysis as cost-efficient as possible while retaining ABB’s rock-solid reputation as the most reliable instruments in the industry.

FAU800 Specifications

Specification Details
Flame Failure Relay Drop-Out Configurable 0.1 to 2.5 seconds
Flame Relay(s) Three total, each with Form C contacts
Flame Relay Contact Ratings 250 Vac, 3A, 750 VA; 220Vdc, 300 mA, 66 watts
Fault Relay Contact Ratings 250 Vac, 3A, 750 VA; 220Vdc, 300 mA, 66 watts
Analog Flame Signal Outputs Two channels of 4-20 mA signals. Each channel may independently monitor Intensity, Frequency, Quality, or AC Amplitude
Serial Data Communication Two galvanically isolated RS-485 interfaces (fully independent for redundancy)
Serial Data Format MODBUS (default), PROFIBUS (optional)
Self-Checking Time Cycle Electronics shall be checked every 0.1 seconds
Ambient Temperature 0° to 60° C, 95% non-condensing atmosphere
Case Dimensions 13 cm height, 12 cm long, 11 cm wide
Electrical Connections Screw terminals, compression type, accepting 12 to 20 wire gauge
Module Mounting DIN Rail Mounted
Power Consumption 4 watts Minimum, 10 watts Maximum, Typical 6 watts
Stacking Limitation 4 modules with power entry on the end module or 7 modules with power entry on the middle module
