Yokogawa EJA530E-JCS7N-012DL/D3/N4 Gauge Pressure Transmitter

Product Description

• The Yokogawa EJA530E-JCS7N-012DL/D3/N4 is an advanced in-line mount gauge pressure transmitter designed for precise and reliable pressure measurement in industrial applications.

• It utilizes Yokogawa’s DPharp digital sensor technology, ensuring high accuracy and long-term stability.

• The transmitter is suitable for measuring the pressure of liquids, gases, and vapors, offering exceptional performance even in harsh environments.

• It features a robust construction with an IP66/IP67 protection rating, making it ideal for outdoor and demanding industrial conditions.

Technical Specifications

• Measurement Range: Configurable based on application requirements

• Accuracy: ±0.055% of span (±0.04% for /HAC option)

• Stability: ±0.1% URL per 10 years (under normal operating conditions)

• Response Time: 90 milliseconds for rapid pressure changes

• Output Signal: 4–20 mA DC with HART communication protocol

• Power Supply: 24 V DC, loop-powered system

• Operating Temperature: -40°C to +85°C (depending on configuration)

• Protection Rating: IP66/IP67, suitable for outdoor and harsh environments

• Range Ratio:

• Capsule A: 20:1

• Capsules B, C, and D: 100:1

• Type of Measurement: Gauge pressure measurement
