ABB CI592-CS31 Interface Module

General Information

• Extended Product Type: CI592-CS31
• Product ID: 1SAP221200R0001
• ABB Type Designation: CI592-CS31
• EAN: 4016779681087
• Catalog Description: Interface module. CS31 slave. 4 AI: U, I, RTD. 2 AO: U, I. 8 DI: 24VDC. 8 configurable DI/DO: 24VDC 0.5A (CI592-CS31)

Ordering

• CN8: 85389091
• Invoice Description: Interface module. CS31 slave. 4 AI: U, I, RTD. 2 AO: U, I. 8 DI: 24VDC. 8 configurable DI/DO: 24VDC 0.5A (CI592-CS31)
• Made To Order: No
• Minimum Order Quantity: 1 piece
• Order Multiple: 1 piece
• Selling Unit of Measure: piece

Dimensions

• Product Net Weight: 0.125 kg
• Product Net Depth / Length: 62 mm
• Product Net Height: 76 mm
• Product Net Width: 67.5 mm
• Gross Weight: 0.149 kg
• Package Level 1 Depth / Length: 84 mm
• Package Level 1 Height: 72 mm
• Package Level 1 Width: 71 mm
• Package Level 1 Units: 1 carton

Technical

• Function: CS31 slave. 4 AI: U, I, RTD. 2 AO: U, I. 8 DI: 24VDC. 8 configurable DI/DO: 24VDC 0.5A
• Number of Hardware Interfaces:
  • Industrial Ethernet: 0
  • Other: 0
  • Parallel: 0
  • RS-232: 0
  • RS-422: 0
  • RS-485: 0
  • Serial TTY: 0
  • USB: 0
  • Wireless: 0
• Analog Inputs: 4
• Analog Outputs: 2
• Number of Digital Inputs: 8
• Number of Digital Outputs: 0
• Number of Digital Configurable I/Os: 8
• Input Voltage Type: DC
• Input Voltage (Uin): 24 V DC
• Input Current: 5 mA
• Delay Time (τ): 0.1 … 32 ms
• Output: Transistor
• Output Voltage Type: DC
• Output Current: 0.5 A
• Output Voltage Maximum: 20.4 … 28.8 V
• Degree of Protection: IP20
• Supply Voltage: 20.4 ... 28.8 V DC
