BENTLY NEVADA 135785-02 Backlit Display Unit For 3500/93

Product Description:

The Bently Nevada 135785-02 is a Backlit Display Unit for the Bently Nevada 3500/93 Machinery Protection System. It provides local or remote visual indications of all system data, including System Event Lists, Alarm Event Lists, and data from Channel, Monitor, Relay Module, Keyphasor, and Tachometer Modules.

Technical Specifications:

• Model Number: 135785-02

• Type: Backlit Display Unit

• Dimensions: 41.5 cm x 20.5 cm x 5 cm (16.5 in x 8.1 in x 2 in)

• Weight: 2.15 kg (4.7 lbs)

• Display Type: Reflective 640 x 200 Dots LCD or Transflective 640 x 200 Dots LCD with white electroluminescent backlight

• Mounting Options: Face Mounting, 19-inch EIA Rack Mounting, Panel Mounting, and Independent Mounting

• Power Supply: Requires External Power Supply for mounting options that require a longer cable (over 100 feet) or backlight

• Certifications: Meets the requirements of the American Petroleum Institute (API) Standard 670

Product Features:

• Backlit Display: Enhances visibility in low-light environments

• Multiple Mounting Options: Can be installed using various mounting methods

• Visual Indications: Displays system information such as alerts, status, and trends
