BENTLY NEVADA 177313-02-01-00 TK-3e Electric Driven

Description

The 177313-02-01-00 TK-3e Proximity System Test Kit is designed to simulate shaft vibration and position, providing a reliable method for calibrating Bently Nevada monitors. It verifies both the operating condition of the monitor readouts and the health of the proximity transducer system. By ensuring proper calibration, the system guarantees accurate transducer inputs and resulting monitor readings.

Physical Size

• Height: 195 mm (7.68 inches)

• Width: 299 mm (11.8 inches)

• Depth: 248 mm (9.76 inches)

• Weight: 5.22 kg (11.5 lb)

Environmental

• Equipment is for indoor use only.

• Maximum altitude: 2000 m

• Operational Temperature Range: 0 °C to 50 °C (32 °F to 122 °F)

• Storage Temperature Range: -18 °C to 65 °C (0 °F to 150 °F)

• Humidity: 95% Non-Condensing

• Exposure: Designed to meet IP54 for dust and water exposure (when closed)

Electric Driven TK-3e

177313-AA-BB-CC

• A: Scale Units

• 02 = Metric

• B: Power Cord Type

• 01 = American

• C: Agency Approvals

• 00 = None
