BENTLY NEVADA 3300/16-13-01-01-00-00-00 Dual Vibration Monitor

3300/16-13-01-01-00-00-00 Dual Vibration Monitor

Description

The 3300/16 XY/Gap Dual Vibration Monitor continuously measures and monitors two independent channels of radial vibration and average shaft position (gap), accepting inputs from two proximity probe/Proximitor® systems. This monitor is designed to supersede the 3300/15 Dual Radial Vibration Monitor, which does not provide radial position gap alarms.

Specifications

Signal Inputs

• Accepts one or two proximity probe signals.
• Input Impedance: 10 kΩ
• Sensitivity:
  • 100 mV/mil (4 V/mm) or
  • 200 mV/mil (8 V/mm) user-programmable.

Power Consumption

• 2 watts (nominal)

Signal Conditioning

• Accuracy at +25°C (+77°F):
  • Within ±0.33% of full-scale typical,
  • ±1% maximum.
  • ±2% maximum with 2X Trip Multiply.
  • ±3% maximum with 3X Trip Multiply.

Recorder Outputs

• User-programmable for:
  • +4 to +20 mA
  • 0 to -10 Vdc
  • +1 to +5 Vdc
• Voltage or current outputs are proportional to programmed monitor full-scale.
• Individual recorder outputs are provided for each channel.
• Monitor operation is unaffected by short circuits on recorder outputs.

Output Impedance (Voltage Outputs)

• 100 Ω.
• Minimum load resistance is 10 kΩ.

Voltage Compliance (Current Outputs)

• 0 to +12 Vdc range across load.
• Load resistance is 0 to 600 Ω when using +4 to +20 mA option.

Recorder Accuracy (in addition to signal conditioning accuracy) at +25°C (+77°F)

• +4 to +20 mA: ±0.7% of signal, ±0.09 mA offset.
• +1 to +5 Vdc: ±1.1% of signal, ±10 mV offset.
• 0 to -10 Vdc: ±1.1% of signal, ±15 mV offset
