Bently Nevada 3500/22M Transient Data Interface

3500/22M Transient Data Interface Module

Description:
The 3500/22M Transient Data Interface (TDI) module acts as the interface between the 3500 monitoring system and compatible software, such as System 1 Condition Monitoring and Diagnostic software and 3500 System Configuration software. It combines the functionalities of the 3500/20 Rack Interface Module (RIM) with data collection capabilities, similar to a communication processor like TDXnet.

Specifications:

Inputs:

• Power Consumption: 10.5 Watts
• Data Connections:
  • Front Panel: USB-B
  • 10Base-T/100Base-TX I/O: Autosensing Ethernet
  • 100Base-FX I/O: Fiber-Optic Ethernet

Outputs:

• Front Panel LEDs:
  • OK LED: Indicates proper operation of the 3500/22M module.
  • TX/RX LED: Signals communication activity with other rack modules.
  • TM LED: Shows when the 3500 rack is in Trip Multiply mode.
  • CONFIG OK LED: Confirms a valid rack configuration.

Environmental Limits:

• Operating Temperature: -30°C to +65°C (-22°F to +149°F)
• Storage Temperature: -40°C to +85°C (-40°F to +185°F)
• Humidity: 95%, non-condensing
• Battery Life:
  • Powered TDI: 38 years at 50°C (122°F)
  • Unpowered TDI: 12 years at 50°C (122°F)

Physical Specifications:

TDI Module:

• Dimensions (HxWxD): 241.3 mm x 24.4 mm x 241.8 mm (9.50 in x 0.96 in x 9.52 in)
• Weight: 0.91 kg (2.0 lbs)

I/O Modules:

• Dimensions (HxWxD): 241.3 mm x 24.4 mm x 99.1 mm (9.50 in x 0.96 in x 3.90 in)
• Weight: 0.20 kg (0.44 lbs)

Rack Space Requirements:

• TDI Module: Requires one full-height front slot.
• I/O Modules: Require one full-height rear slot.
