Bently Nevada 990-05-50-01-CN 990 Vibration Transmitter

Bently Nevada 990-05-50-01-CN Vibration Transmitter

The Bently Nevada 990-05-50-01-CN is a high-performance Vibration Transmitter designed to monitor machinery condition with precision. Below are its specifications and features:

Technical Specifications

• Model Number: 990-05-50-01-CN
• Measurement Range: 0 to 5 mils peak-to-peak (0 to 125 microns)
• System Length: 5.0 meters (16.4 feet)
• Output Signal: 4-20 mA current loop
• Power Supply: +12 to +35 Vdc input at the transmitter terminal
• Operating Temperature Range: -35°C to +85°C (-31°F to +185°F)
• Storage Temperature Range: -51°C to +100°C (-60°F to +212°F)
• Protection Rating: IP65
• Dimensions: 127 mm x 127 mm x 100 mm (5 in x 5 in x 4 in)
• Weight: 1.5 kg (3.3 lbs)
• Certifications: CSA/NRTL/C, ATEX/IECEx
• Shipping Weight: 1.5 kg (3.3 lbs)
• Made in: U.S.A

Features

• Integrated Proximitor Sensor: Eliminates the need for an external unit.
• Non-Isolated Terminals: Offers dynamic vibration and gap voltage signal output for diagnostics.
• Adjustable Settings: Includes non-interacting zero and span potentiometers for precise loop adjustments.
• Test Input Pin: Enables quick loop signal output verification using a variable DC voltage source.
• Power-Up Inhibit Circuit: Mitigates signal errors caused by line voltage transients.
• Not OK/Signal Defeat Circuit: Prevents false alarms or high outputs from faulty proximity probes or loose connections.
• Mounting Flexibility: Supports installation with DIN-rail clips or bulkhead mounting screws.
• Potted Construction: Withstands high humidity environments, tolerating up to 100% condensation.
• Compatibility: Designed to operate with 3300 NSv proximity probes, making it suitable for small, restricted installation areas like centrifugal air compressors.
