Bently Nevada 991-06-50-01-CN Thrust Transmitter

The Bently Nevada 991-06-50-01-CN is a Thrust Transmitter designed for machinery condition monitoring. Here are its key specifications and features:

Technical Specifications:

• Model Number: 991-06-50-01-CN

• Measurement Range: 0 to 0.6 mm (0 to 0.024 in)

• System Length: 5.0 meters (16.4 feet)

• Output Signal: 4-20 mA current loop

• Power Supply: 12 to 30 Vdc

• Operating Temperature Range: -40°C to +85°C (-40°F to +185°F)

• Protection Rating: IP65

• Dimensions: 127 mm x 127 mm x 100 mm (5 in x 5 in x 4 in)

• Weight: 2 kg (4.4 lbs)

• Certifications: CSA/NRTL/C, ATEX/IECEx

• Shipping Weight: 2 kg (4.4 lbs)

• Made in: U.S.A

Features:

• Integrated Proximitor Sensor: Eliminates the need for an external unit, simplifying installation.

• Signal Outputs: Includes non-isolated "PROX OUT" and "COM" terminals for dynamic vibration and gap voltage diagnostics.

• Adjustable Settings: Non-interacting zero and span potentiometers for easy loop adjustments.

• Test Input Pin: Allows quick verification of loop signal output using a variable DC voltage source.

• Power-Up Inhibit Circuit: Prevents signal errors due to line voltage transients.

• Not OK/Signal Defeat Circuit: Avoids false alarms from faulty probes or loose connections.

• Mounting Flexibility: Options for DIN-rail clips or bulkhead mounting screws simplify installation.

• Potted Construction: Designed for high humidity environments, tolerating up to 100% condensation.

• Compatibility: Works with 3300 NSv proximity probe for installations in tight spaces typical of centrifugal air compressors
