GE Fanuc IC697VAL318 8-Channel Analog Output Module
GE Fanuc IC697VAL318 8-Channel Analog Output Module
Product Type: 8-channel analog output module
Payment:T/T, Western Union
Shipping Port:Jinhua China
Lead Time:1-3 Working Days
Condition: Brand New And 100% Original
Warranty: 12 months
The GE Fanuc IC697VAL318 is an 8-channel analog output module belonging to the GE Fanuc Series 90-70 family. It functions as the opposite counterpart to the IC697MEM715 you previously inquired about, taking digital control signals from the PLC and converting them into analog voltage outputs for various applications. Here's a breakdown of its specifications and features:
Specifications:
Number of channels: 8 independent analog output channels.
Output voltage range: Programmable output range of 0-10 VDC or ±10 VDC, allowing versatility for different applications.
Resolution: 12-bit Digital-to-Analog Converter (DAC), providing 4096 discrete levels for each channel, enabling precise control of the analog output voltage.
Update rate: Programmable update rate up to 1 kHz (kilohertz) for refreshing the output voltage at desired intervals.、
Features:
High accuracy: Delivers reliable and accurate conversion of digital signals from the PLC into analog voltage outputs for precise control applications.
Multiple output ranges: Supports a configurable output range of 0-10 VDC or ±10 VDC, making it compatible with various actuators and devices requiring specific voltage ranges.
Programmable gain and offset: Enables fine-tuning the output scaling to match the specific actuator or device requirements for optimal control.
Channel-to-channel isolation: Isolates each output channel electrically, preventing electrical noise or ground loops from affecting other channels or the PLC itself, ensuring reliable signal integrity.
Applications:
Industrial automation: Used in various industrial applications to control and regulate analog devices based on digital signals from the PLC, such as:
Process control: Controlling process variables like pressure, temperature, flow rate, and level by adjusting the output voltage to actuators like valves, pumps, and heaters.
Machine control: Controlling the speed and position of motors, actuators, and other devices by providing precise analog voltage signals.
Signal generation: Generating analog signals for testing, calibration, and simulation purposes.
View full details
Specifications:
Number of channels: 8 independent analog output channels.
Output voltage range: Programmable output range of 0-10 VDC or ±10 VDC, allowing versatility for different applications.
Resolution: 12-bit Digital-to-Analog Converter (DAC), providing 4096 discrete levels for each channel, enabling precise control of the analog output voltage.
Update rate: Programmable update rate up to 1 kHz (kilohertz) for refreshing the output voltage at desired intervals.、
Features:
High accuracy: Delivers reliable and accurate conversion of digital signals from the PLC into analog voltage outputs for precise control applications.
Multiple output ranges: Supports a configurable output range of 0-10 VDC or ±10 VDC, making it compatible with various actuators and devices requiring specific voltage ranges.
Programmable gain and offset: Enables fine-tuning the output scaling to match the specific actuator or device requirements for optimal control.
Channel-to-channel isolation: Isolates each output channel electrically, preventing electrical noise or ground loops from affecting other channels or the PLC itself, ensuring reliable signal integrity.
Applications:
Industrial automation: Used in various industrial applications to control and regulate analog devices based on digital signals from the PLC, such as:
Process control: Controlling process variables like pressure, temperature, flow rate, and level by adjusting the output voltage to actuators like valves, pumps, and heaters.
Machine control: Controlling the speed and position of motors, actuators, and other devices by providing precise analog voltage signals.
Signal generation: Generating analog signals for testing, calibration, and simulation purposes.
