GE PCI-5565 Fiber Optic Network Card

GE PCI-5565:

• High-Speed Fiber Optic Network:

  • Data rate of 2.125Gbps for fast and efficient data transfer.

• CPU-Independent Operation:

  • Data transfer occurs without CPU intervention, reducing system overhead and improving performance.

• Flexible Topology:

  • Supports both ring and star network topologies to accommodate various system configurations.

• PCI Bus Compatibility:

  • Compatible with 33MHz/66MHz 64-bit/32-bit PCI bus.
  • Supports both 3.3V and 5.0V levels.

• Redundancy:

  • Optional redundant transmission mode for increased reliability.

• Scalability:

  • Supports up to 256 nodes in a network.

• Long-Distance Transmission:

  • Supports multimode transmission up to 300 meters.
  • Single-mode transmission up to 10km.

• Automatic Packet Size Adjustment:

  • Automatically adjusts packet size from 4 to 64 bytes for optimal performance.

• Large Onboard Memory:

  • Includes 256MB of onboard memory with error checking.

• Low Latency:

  • Offers a low latency of 0.4 microseconds for real-time applications.

• Independent DMA Channel:

  • Provides a dedicated DMA channel for efficient data transfer.

• Interrupt Support:

  • Supports 32-bit data network interrupts.

• Endian Conversion:

  • Allows for endian conversion for different system architectures within the same network.

• Operating System Support:

  • Supports various operating systems including Windows, Linux, VxWorks, RTX, DOS, and LabVIEW RT.
