Honeywell 51309288-375 Analog Input Module In Stock

The Honeywell 51309288-375 is a 16-channel analog input module with high level termination, HART support, and Ethernet communication. It is part of the Honeywell Experion LX distributed control system (DCS) Series 8 I/O family. The 51309288-375 is a coated module, which means that it has a conformal coating applied to the electronics circuitry to protect it from moisture, dust, chemicals, and temperature extremes.

Specifications:

• Input type: voltage, current (2-wire or self-powered transmitters), single-ended or differential inputs
• Input channels: 16
• Input range: 0 to 5 V, 1 to 5 V, 0.4 to 2 V, 4-20 mA (through 250 Ω)
• Voltage rating: 24 VDC
• Module current rating: 310 mA
• Common mode rejection ratio: 70 dB
• Common mode voltage: -6 to +5 V peak
• Normal mode rejection ratio: 19 dB
• Normal mode filter response: single-pole RC, -3 dB @ 6.5 Hz
• Crosstalk: -60 dB
• Communication: Ethernet

Key Features:

• 16-channel analog input with high level termination, HART support, and Ethernet communication
• Coated for protection against harsh environments
• Wide variety of input signals accepted
• 16-bit A/D converter resolution
• High common mode rejection ratio
• High normal mode rejection ratio
• High accuracy
• Supports HART communication
• Supports Ethernet communication

Applications:

• Process control
• Machine control
• Data acquisition
• Test and measurement
• Research and development
