Kongsberg RDIOR400 Interface Module

The Kongsberg RDIOR400 is an interface module designed for use in Kongsberg Maritime automation systems, providing reliable digital input and output capabilities.

Key Features

• Channels: Up to 32 individually defined digital inputs or outputs.
• Interface: Dual Serial Process Bus (SPBus) interfaces for optional redundancy.
• Applications: Suitable for industrial automation and process control.
• Input/Output Types: Configurable as digital input or output channels.
• Protection: Electrical isolation from the control system, short-circuit proof loop current driver, and fail-safe activation of outputs upon loss of communication.
• Diagnostics: Built-in test for self-diagnostics and fault identification, including Line Fault Detection (LFD) and Earth Fault Detection (EFD).

Technical Specifications

• Input Supply Voltage: 24 VDC ± 20%
• Power Consumption: Typical 8 W

Digital Input (DI)

• Loop voltage: 24 VDC ± 20%
• Max input voltage: 30 VDC
• Max input signal frequency: 10 ms pulses
• Input loop current: Max. 4 mA @ 24 VDC
• Channel “Off” current: < 0.5 mA
• Channel “On” current: > 3 mA

Digital Output (DO)

• Loop voltage: 24 VDC ± 20%
• Loop driver: 1 A, short-circuit proof “High-Side Driver” (HSD)
• Loop driver trip current: Approx. 1.4 A (reset by command)
• Loop driver Off leakage: Max. 2 mA @ 24 VDC

SPBus Interface

• SPBus interfaces: 2
• Power supply voltage from SPBus: 10 to 28.8 VDC
• SPBus connector: 9-pin male DSUB
• SPBus isolation: 500 V (optocoupler)
• SPBus type: RS-485 (multidrop)
• SPBus frequency: Max. 2 MHz
• SPBus signal code: Manchester encoded (self-clocked)

Environmental Specifications

• Operating temperature: -15°C to +70°C
• Storage temperature: -25°C to +70°C
• Humidity: Up to 98% RH
• Protection standards: IP20 (IEC 60529)
