SCHNEIDER 140DAO84000C Discrete Output Module

The Schneider 140DAO84000C is a discrete output module for the Modicon Quantum automation platform. It controls actuators, relays, and other devices based on logic signals received from the CPU. Here's a breakdown of its key specifications, features, and applications:

Specifications:
Type: Discrete output module
Voltage: AC (20…253 V)
Number of channels: 16
Logic: Positive (sink)
Communication: Quantum bus
Output current:
3 A per channel, continuous
6 A per channel, peak for 1 second
Maximum switching power: 300 VA per channel (120 V) or 600 VA per channel (230 V)
Leakage current: < 1 mA per channel

Features:
Positive Logic: A logic "1" is represented by a high voltage (between 20 and 253 V) on the output channel, while a logic "0" is represented by a low voltage (less than 5 V).
LED indicators: LEDs show the status of each output channel, aiding troubleshooting.
Channel configuration: Individual or group configuration for flexible device control.
Short circuit protection: Protects the module and connected devices from damage.
Green Premium label: Complies with environmental regulations and uses sustainable materials.

Applications:
The 140DAO84000C is used in various industrial applications where you need to control actuators and devices based on logic signals, such as:
Process control: Operating valves, pumps, and other equipment in manufacturing processes.
Machine control: Driving motors, solenoids, and other actuators on machines.
Building automation: Controlling lighting, HVAC systems, and other building equipment.
Power generation: Managing circuits, breakers, and other equipment in power plants.
