SCHNEIDER BMXAMI0410 Aanalog Input Module

The Schneider Electric BMXAMI0410 is a compact analog input module for the Modicon X80 Programmable Logic Controller (PLC) system. It's designed for situations where you need to convert analog signals from sensors or transducers into digital data the PLC can process and understand, but with a smaller footprint compared to modules with more channels.

Here's a breakdown of its key specs, features, and applications:

Specifications:
Number of channels: 4 isolated analog inputs
Input signal types: 0 to 20mA, 4 to 20mA, or ±10V
Input impedance: 1 MΩ for voltage inputs, 250 Ω for current inputs
Resolution: 12 bits
Accuracy: ±0.1% of full scale
Sampling rate: Up to 10 kHz
Operating temperature: -25°C to +70°C
Dimensions: 40 x 65 x 55 mm (WxLxH)

Features:
Compact design: Saves space in the PLC cabinet, ideal for applications with limited space.
Plug-and-play configuration: Simplifies setup and integration with the Modicon X80 PLC.
Multiple input types: Supports various industry-standard analog signals for versatility.
High accuracy and resolution: Ensures precise data acquisition for reliable control.
LED indicators: Provide visual status information for each input channel.

Applications:
The BMXAMI0410 is suitable for various industrial automation scenarios where the Modicon X80 PLC is employed and analog signal acquisition is required, particularly in situations where space is limited. Some common examples include:
Machine control: Monitoring temperature, pressure, flow, and vibration on machines with limited control cabinet space.
Process control: Monitoring and controlling key process variables in small-scale or distributed control systems.
Building automation: Monitoring indoor air quality, temperature, and energy consumption in smaller buildings or specific zones.
Environmental monitoring: Tracking environmental parameters like air quality, water quality, and noise levels in compact monitoring stations.
