SCHNEIDER TSXDSZ08R5 Relay Output Module

The Schneider TSXDSZ08R5 is a relay output module within the Modicon TSX Micro range by Schneider Electric. It serves as the interface between the PLC and devices requiring control signals, like motors, valves, and solenoids. Essentially, it translates the PLC's digital output commands into physical on/off switching for these devices.

Here's a breakdown of its key aspects:

Specifications:
Function: 8-channel relay output module
Voltage: 19.2...30 V DC (input), 24V DC or 24...240V AC (output)
Output type: Normally Open (NO) contacts
Maximum output current: 1.5 A per channel
Power consumption: 1.5 W
Connection: Screw terminal block
Degree of protection: IP20

Features:
8 isolated output channels: Each channel controls a separate device.
Normally Open (NO) contacts: The circuit is open by default and closes when activated by the PLC.
Wide output voltage range: Suitable for controlling various types of devices.
LED indicators: Provide visual status for each output channel (on/off).
Compact design: Saves space in control cabinets.
Easy installation and wiring: Screw terminal block simplifies connections.
Compliance: CE, UL

Applications:
Machine control: Activating actuators, solenoids, valves, etc.
Building automation: Controlling lighting, HVAC systems, alarms, etc.
Process control: Operating pumps, valves, heaters, etc.
Test and measurement: Controlling test equipment and actuators.
Data acquisition: Triggering data acquisition events.

In summary, the Schneider TSXDSZ08R5 is a versatile and reliable output module suitable for controlling various devices in industrial automation, building automation, and other applications requiring digital-to-physical signal conversion.
