SCHNEIDER TSXT3170 Compact Communication Module

The Schneider TSXT3170 is a powerful and compact communication module for the Modicon TSX 57 PLC system. It enables the PLC to communicate with other devices and systems over various communication protocols, allowing for data exchange, remote control, and overall system integration.

Here's a breakdown of its features and specifications:
Multi-protocol support: Supports a wide range of communication protocols, including Modbus, Profibus, and CANopen, providing flexibility for different application requirements.
Dual communication ports: Equipped with two independent communication ports, enabling simultaneous connections to multiple networks or devices.
High data rates: Offers fast data transfer speeds for efficient communication and real-time applications.
Configuration flexibility: Can be easily configured through software tools for specific communication protocols and network settings.
LED indicators: Provides visual status information for power, communication activity, and potential errors.
Compact design: The module's small size makes it suitable for applications where space is limited.

Specifications:
Power supply: 24 VDC
Operating temperature: -25°C to +70°C
Dimensions: 65 x 85 x 25 mm (approximately the size of a deck of cards)

Applications:
Factory automation: Connecting the PLC to sensors, actuators, and other devices on the factory floor for data acquisition, control, and monitoring.
Building automation: Integrating the PLC with building management systems for HVAC control, lighting control, and security systems.
Remote monitoring and control: Enabling remote access to the PLC for data monitoring, parameter adjustments, and system control from a central location.
Data acquisition and logging: Collecting data from various sources and storing it for analysis and reporting purposes.

The Schneider TSXT3170 serves as a crucial communication bridge for the Modicon TSX 57 PLC, enabling it to seamlessly interact with diverse devices and systems within an industrial or building automation environment.
