WAGO 750-556 Analog Output Module In Stock

The WAGO 750-556, like the 750-555, is a 4-channel analog output module within the WAGO-I/O-SYSTEM family. However, there are some key differences between the two, especially in terms of output type and functionalities.

Specifications:

1. Output voltage range: 0-10V or ±10V (switchable) PWM
2. Output current range: 4-20mA PWM
3. Resolution: 12 bits (PWM frequency)
4. Update rate: Up to 10kHz
5. Power supply: Internal system supply or external 24VDC
6. Operating temperature range: -25°C to +70°C

Features:

1. 4-channel analog output: Converts digital control signals into 4 independent analog voltage or current outputs (depending on model).
2. Output type: Primarily designed for pulse-width modulated (PWM) voltage or current outputs. This means the signal rapidly switches between high and low states, with the ratio of "on" time to "off" time determining the average voltage or current delivered.
3. Resolution: Typically 12 bits for PWM frequency, allowing for precise control over the average output.
4. Fast update rate: Can reach up to 10kHz, making it suitable for controlling dynamic processes with rapid changes.
5. Electrically isolated: Ensures safe operation by protecting against interference and ground faults.

Applications:

1. Controlling motors with PWM-based variable speed drives.
2. Driving actuators like valves and solenoid coils with precise pulse-width modulation.
3. Dimming LEDs and other lighting systems with PWM control.
4. Generating PWM signals for testing and research purposes.
5. Interfacing with devices requiring PWM inputs for precise control.
